Vacuum Calibration Tank – Precision Cooling & Sizing for Pipe Extrusion Lines

Our Vacuum Calibration Tank is engineered for high‑speed plastic pipe extrusion, delivering accurate sizing, uniform wall thickness, and a smooth surface finish. Available in single‑ or double‑chamber configurations, it integrates VFD‑controlled vacuum (energy‑saving), a patented automatic water level control, and a centralized water supply with optimized nozzle layout. Built from stainless steel, it reliably cools and calibrates PVC, HDPE, PPR, and PE pipes from 16mm up to 1200mm diameter. Reduce energy costs, minimize scrap, and achieve consistent quality – line after line.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Vacuum Calibration Tank for PVC / HDPE / PPR Pipe Extrusion Lines

Our single‑chamber and double‑chamber vacuum calibration tanks are designed for precise cooling and sizing of plastic pipes. They ensure high dimensional stability, roundness, and surface finish for PVC, HDPE, and PPR pipe production.

Key Features

Stainless steel construction for long service life
Large viewing windows with inspection lamps
Adjustable spraying nozzles for uniform cooling
High‑efficiency vacuum system with fast response
Available in single‑chamber or double‑chamber design
Easy access for cleaning and maintenance

Technical Specifications

Material compatibility	PVC, HDPE, PPR, and other thermoplastics
Pipe diameter range	16–630 mm (customizable)
Vacuum pump power	2.2 – 7.5 kW
Cooling method	Water spray / immersion
Material	Stainless steel 304 / 316

All tanks are supplied with complete vacuum and water recirculation systems. Optional features include digital vacuum control, automatic water level regulation, and customised lengths.

For detailed quotation or technical drawings, please contact our sales team.
